Fig. 106: Laue pattern from MbCO recorded in a single pulse of 150 picoseconds. The pattern contains ca 2000 reflections at 1.8 Å resolution. The pattern was recorded on a CCD detector coupled to an image intensifier. The bandwidth is 7-38 keV and the incident polychromatic flux through the sample is 8 x 1010 photons per pulse.
